Window Cleaning Robot
Window Washing Robot
  • Window Washing RobotWindow Washing Robot

Window Washing Robot

Model:311
The 311 Window Washing Robot offered by LIESA, a professional manufacturer from China, is suitable for automated cleaning of smooth vertical surfaces. Weighing only 1.4kg, it combines bidirectional atomizing spray, 10 cleaning modes, UPS backup suction and multiple sensors, with 65dB low-noise operation for residential and commercial use.
    Rating: 5.0
    (Rating Count: 1)

    The LIESA Model 311 Window Washing Robot is designed around a compact and lightweight structure for routine cleaning of suitable vertical glass and smooth surfaces. This China factory model uses engineering-grade ABS, a bidirectional automatic spray system, intelligent pressure monitoring and N/Z cleaning paths. Its infrared remote control, optional APP control, backup battery and 5-meter safety rope provide a practical operating system for household windows, commercial glass and other compatible vertical surfaces.

    Product Specifications

    Model

    311(square shape)



    Specification





    Color

    White/Black/Custom



    Unit Dimensions (L*W*H) mm

    229*229*65 (including wheel height)



    Unit Material

    Engineering-grade ABS



    Unit Net Weight (kg)

    1.4



    Gross Weight (including 1in1 carton, kg)

    2.6 kg



    Base Dimensions (L*W*H) mm

    373*262*87 mm



    1in1 Carton Dimensions (L*W*H) mm

    388*100*285 mm



    5in1 Carton Dimensions (L*W*H) mm

    545*405*310 mm



    Top Cover Logo

    YiYin/Sticker



    Feature

    Description

    Working Modes

    1. N-pattern cleaning,

    2. Z-pattern cleaning,

    3. Upward cleaning,

    4. Downward cleaning,

    5. Leftward cleaning,

    6. Rightward cleaning,

    7. Full-point cleaning,

    8. XZ-axis cleaning (N+Z),

    9. Left-only N-pattern cleaning,

    10. Right-only N-pattern cleaning

    Backup Battery Operating Time

    Approx. 20-30 mins

    Charging Time

    Approx. 2.0 h

    Operating Noise

    Approx. 65 dB

    Operating Temperature & Humidity Range

    0-40°C / 85% RH

    Rated Power

    72 W

    Rated Voltage

    24 V

    Service Life

    ≥400 h

    Bidirectional Auto Water Spray

    Yes (Atomized)

    Number of Spray Heads

    2 (Dual-side spray, 1 head per side)

    Water Spray Volume

    0.17 ml/min

    Effective Spray Area

    Approx. 120 m²

    Low Water Alarm

    Yes (Motorized water valve)

    Edge Air Pressure Detection

    Yes

    Variable Frequency Airflow Algorithm

    Yes

    Antifreeze Control Algorithm

    Yes

    UPS (Uninterruptible Power Supply)

    Yes

    Automatic Air Spray Adjustment

    Yes

    Belt Self-Cleaning

    Yes

    Anti-slip Belt

    Yes

    Hybrid Management

    Yes

    Multi-language Support

    Yes (Chinese + 1 language included; additional languages available at extra cost)

    Fan Speed

    31,500 RPM ±10% (No load)

    Speed Settings

    Fixed

    Maximum Vertical Drop Under Timed Spray

    5.5 kgf

    Fan Operating Pressure

    2400-2800 Pa

    Manual Update

    Yes

    Low Battery Alarm

    Yes

    Control Method

    Remote control (Infrared) / APP (Optional)

    Minimum Working Area Size

    60 * 40 cm

    Applicable Spray Coating Thickness

    ≥3 mm

    Suitable Applications

    Deep pools, garden landscapes, large stone walls, fountains, wooden doors, etc.

    Feature

    Sub-feature / Specification

    Details

    Indicator Light

    Power indicator / Different color meanings

    Yes

    Motor

    Momentary motor type

    DC Brushless Motor (Full air-cooled)



    Drive motor type

    2 pcs DC Brushless Motors

    Battery

    Battery type

    Cylindrical Lithium-ion Cell



    Battery capacity (mAh)

    500 (4 x 14500 cylindrical batteries)



    Charging current (mA)

    Approx. 230 (at constant current)

    Water Tank

    Capacity (ml)

    60



    Water spray

    Dual-row ceramic nozzles (2*1)

    Adapter

    Input: AC(V), Frequency(Hz), Current(A)

    AC 100~240V, 50/60Hz, 2.0A



    Output: Voltage(V), Current(A)

    24V / 3.0A

    Safety Line

    Safety guard (Kgf)

    135



    Safety rope length

    Approx. 5m

    Other

    Quantity

    2



    Dimensions (LWH) mm

    233 * 233 * 4.0

    Sensors

    6-axis sensor

    1



    Photoelectric sensor

    4



    Water level sensor

    1



    Highly sensitive air pressure sensor

    /

    Certifications

    CE

    Yes



    FCC ID

    Yes



    RoHS

    Yes



    WEEE

    Yes

    Installation Data

    20Hz container capacity

    2200 pcs



    40Hz container capacity

    4300 pcs



    40HQ container capacity

    5200 pcs

    Key Features & Benefits

    1. Lightweight 1.4kg Body

    The Window Washing Robot uses an engineering-grade ABS housing and has a net weight of only 1.4kg. The compact weight makes the robot easier to position, remove and handle during routine cleaning.

    2. Bidirectional Automatic Water Spray

    A bidirectional atomizing spray system distributes water from both sides of the cleaning area. The atomized spray supports wet cleaning and helps loosen surface dirt before wiping.

    3. 10 Cleaning Modes

    The robot provides 10 cleaning modes, including N-pattern, Z-pattern and spot-cleaning functions. Multiple cleaning routes allow the machine to adapt its movement to different cleaning tasks and suitable glass sizes.

    4. UPS Backup Suction After Power Failure

    The built-in UPS backup battery can maintain suction for approximately 20–30 minutes after power failure. A 5-meter safety rope is also supplied to provide additional physical protection during vertical operation.

    5. Intelligent Pressure and Edge Monitoring

    The 311 incorporates multiple sensors for air-pressure monitoring and edge detection. Its automatic air-pressure adjustment algorithm helps the robot respond to changes during cleaning and maintain more stable operation on suitable surfaces.

    6. Automatic and Manual Control

    The robot supports automatic cleaning operation while also providing infrared remote control for manual handling. APP control is available as an optional function, providing an additional control method for selected configurations.

    7. 65dB Low-Noise Operation

    With operating noise of approximately 65dB, the LIESA 311 is designed for use in residential and commercial environments where keeping operating noise under control is important.

    8. 60 × 40cm Minimum Working Surface

    The robot supports a minimum working surface size of 60 × 40cm. This specification helps buyers confirm whether a target window or other smooth vertical surface is suitable before use.

    Cleaning Functions

    N-Pattern and Z-Pattern Cleaning

    The N- and Z-shaped movement paths provide different automatic cleaning routes for suitable vertical surfaces. Users can select the appropriate mode according to the cleaning task.

    Spot Cleaning

    The spot-cleaning function is designed for localized cleaning tasks where a particular area requires additional attention.

    Automatic Route Control

    The robot can automatically execute preset cleaning routes, reducing the need for continuous manual movement during routine operation.

    Safety and Protection

    The LIESA 311 combines several safety-related functions for vertical surface operation.

    UPS Backup Battery

    Maintains suction for approximately 20–30 minutes after power failure.

    5m Safety Rope

    Provides additional physical restraint during elevated cleaning tasks.

    Edge Detection

    Built-in sensors detect the working surface boundary to help manage the cleaning path.

    Air-Pressure Monitoring

    The sensor system monitors pressure conditions and works with the automatic pressure-adjustment algorithm during operation.

    Low-Battery Alert

    The robot provides a low-battery reminder to alert the user when battery power is low.

    Applicable Surfaces

    The Window Washing Robot is designed for smooth vertical surfaces and can be used on suitable:

    • Glass windows
    • Floor-to-ceiling windows
    • Glass doors
    • Smooth tile surfaces
    • Suitable stone surfaces
    • Other compatible smooth vertical surfaces

    Before operation, the target surface should be checked to ensure that its material, flatness and condition are suitable for stable robot adhesion.

    Application Scenarios

    High-Rise Residential Windows

    The compact 1.4kg design and automatic cleaning functions make the LIESA 311 suitable for routine cleaning of compatible residential windows.

    Apartment Buildings

    The robot can be used for suitable smooth vertical glass surfaces in apartments and residential properties.

    Commercial Buildings

    It is suitable for cleaning compatible glass surfaces in offices, shops and other commercial buildings.

    Floor-to-Ceiling Windows

    The robot can be applied to large smooth vertical glass surfaces such as residential and commercial floor-to-ceiling windows, provided the minimum working-surface requirement is met.

    Glass Doors and Smooth Wall Surfaces

    The machine can also be used on suitable glass doors, smooth tile and stone surfaces.

    Control System

    Infrared Remote Control

    The infrared remote controller provides direct control over the robot, allowing the user to manage cleaning movements and operating modes.

    Optional APP Control

    For configurations supporting the function, APP control provides an additional operating method for users who prefer mobile-device interaction.

    Automatic Pressure Adjustment

    The built-in control algorithm automatically adjusts air pressure according to operating conditions to support stable adhesion and movement.

    Anti-Freeze Control

    The anti-freeze function is incorporated into the control system to support operation under applicable low-temperature conditions.

    Product Design

    The Window Washing Robot combines its lightweight ABS housing with a practical cleaning and control system:

    Engineering-Grade ABS Housing

    Provides the main structural enclosure while keeping the machine at a net weight of 1.4kg.

    Bidirectional Spray Assembly

    Applies water from both sides of the cleaning area for wet-cleaning operation.

    Multiple Sensors

    Support edge recognition and air-pressure monitoring during operation.

    Multiple Cleaning Routes

    Provide 10 cleaning modes, including N-pattern and Z-pattern movement.

    Backup Power

    Maintains suction for approximately 20–30 minutes after power interruption.

    OEM and Private Label Support

    The LIESA Model 311 is available for OEM and private-label projects.

    Available options include:

    Custom Logo

    Branding can be applied to the machine according to the agreed specification.

    Body Color

    Product colors can be adjusted for different brand identities and market positioning.

    Custom Packaging

    Retail color boxes and outer packaging can be developed for overseas sales channels.

    Accessory Configuration

    Accessory combinations can be adjusted according to the agreed purchasing requirements.

    These options are suitable for cross-border e-commerce sellers, offline retailers and commercial cleaning equipment distributors.

    FAQ

    Q1: What cleaning modes does the Window Washing Robot support?

    The robot provides 10 cleaning modes, including N-pattern, Z-pattern and spot-cleaning functions. Infrared remote control is standard, while APP control is available as an option.

    Q2: What happens if the power supply is interrupted?

    The built-in UPS backup battery can maintain suction for approximately 20–30 minutes after power failure. A 5-meter safety rope is also supplied for additional physical protection.

    Q3: What is the minimum working surface size?

    The minimum applicable working surface is 60 × 40cm. Surfaces smaller than this size are not recommended because the robot may not be able to maintain full contact with the working area.

    Q4: How much does the LIESA 311 weigh?

    The robot has a net weight of approximately 1.4kg, making it relatively easy to position and remove during operation.

    Q5: Does the robot support APP control?

    Yes. Infrared remote control is standard, and APP control is available as an optional configuration.

    Q6: What safety functions does the robot provide?

    The LIESA 311 includes UPS backup suction, a 5-meter safety rope, edge detection, air-pressure monitoring and low-battery warning to support safer vertical-surface operation.

    Q7: What certifications does the LIESA 311 have?

    The supplied product information lists CE, FCC ID, RoHS and WEEE compliance credentials.

    Q8: Can the LIESA 311 be customised for our brand?

    Yes. OEM options include custom logo, body color, packaging and accessory configuration according to the agreed project requirements.
