High Speed Window Robot Cleaner
Purchase High Speed Window Robot Cleaner from Liesa, a window cleaning robot supplier from China. Our High Speed Window Robot Cleaner uses high-speed simulated wiping, strong adsorption & intelligent path planning to finish glass cleaning quickly, making home windows clear & bright without manual work.
As a professional factory in China, Liesa's High Speed Window Robot Cleaner has complete international certifications, stable quality and long service life. It is widely used in home, apartment & villa scenes, and trusted by global buyers.
Product Definition
Liesa factory's High Speed Window Robot Cleaner is an automatic intelligent window cleaning machine. It uses vacuum adsorption to attach to glass, runs at high speed to simulate manual wiping, with atomizing water spray to dissolve dirt. It cleans home windows, French windows, balcony glass & shower room glass automatically. One-key operation, no climbing & no danger, saving time and effort for daily cleaning.
Technical Parameters
|
Product Name |
Liesa High Speed Window Robot Cleaner |
|
Suction Power |
3200Pa |
|
Cleaning Speed |
200r/min |
|
Water Tank Capacity |
100ml |
|
Power-Off Adsorption Time |
20 minutes |
|
Product Weight |
1.8kg |
|
Product Certifications |
3C, CE, CB, FCC, ETL, GS, PSE, KTL |
More Specifications
| Window Cleaning Robot Product Specifications | |||
| Overview | Model | 309 PRO | |
| Product Name | Dual-Sided Spraying Window Cleaning Robot | ||
| Color | White / Pink | ||
| Appearance (Design Rendering) | |||
| Packing List | Main Unit (with built-in battery pack) × 1, Power Adapter × 1, AC Power Cord, DC Extension Cord × 1, Cleaning Cloths × 8, Safety Rope × 1, Remote Control × 1, User Manual × 1, Spray Bottle × 1, Battery × 1 | ||
| Detailed Specifications | |||
| Package | Color | White / Pink | |
| Main Unit Dimensions (L×W×H) mm | 269*136*78 | ||
| Main Unit Material | ABS+PC | ||
| Main Unit Net Weight (kg) | 1.18 | ||
| Overall Gross Weight (incl. 1-in-1 Master Carton, kg) | 2.45 | ||
| Color Box Dimensions (L×W×H) mm | 320x86x287mm | ||
| 1-in-1 Master Carton Dimensions (L×W×H) mm | 335x96x315mm | ||
| 5-in-1 Master Carton Dimensions (L×W×H) mm | 505x350x335mm | ||
| Front Cover Logo | Silk Screen Printing | ||
| Function | Operating Mode | 1. Clean Upwards 2. Clean Downwards3. Clean Leftwards 4. Clean Rightwards 5. Spot Cleaning6. X1 Mode Cleaning (Dry/Wet Mopping; adjustable water volume for wet mopping—Small/Large—with Small as default) 7. X2 Mode Cleaning (Dry/Wet Mopping; adjustable water volume for wet mopping—Small/Large—with Small as default) | |
| Backup Battery Charging Time (h) | Approx. 2.5 hours | ||
| Backup Battery Runtime (min) | 20–30 minutes | ||
| Operating Noise (dB) | Approx. 68 dB | ||
| Operating Temperature & Humidity Range (°C / %) | 0–40°C; ≤85% RH | ||
| Operating Speed (min/m²) | Approx. 4 min 40 sec per square meter; one full water tank covers 18 square meters | ||
| Rated Power (W) | 72 W | ||
| Rated Voltage (V) | 24 V | ||
| Unit Lifespan (h) | ≥400 Pa | ||
| Suction Motor Speed (rpm) | 29,000 RPM ±10% | ||
| Speed Settings | Automatic Adjustment | ||
| Vacuum Pressure (Pa) | 2000–3200 RPM (Variable Frequency) | ||
| Manual Update (Firmware) | Yes | ||
| Low Battery Alarm | Yes (Buzzer) | ||
| Control Method | Remote Control (2.4G) — Controllable range: up to 25 meters | ||
| Minimum Working Surface Size (cm) | 30*30 | ||
| Water Spray Settings | 2 Levels | ||
| Water Spray Volume (ml/spray) | Small Setting: Approx. 0.06 ml/s; Large Setting: Approx. 0.09 ml/s | ||
| Water Spray Method | Atomizing Nozzle (Bi-directional Spray) | ||
| Water Level Detection | None | ||
| Applicable Surfaces | Glass, tiles, wooden doors, marble walls, and other smooth vertical surfaces | ||
| Structure | Solenoid Valve | Voltage | 24V |
| Indicator Light | Battery Indicator / Meaning of Indicator Light Colors | Yes | |
| Water Tank | Capacity (ml) | 60 ml | |
| Motor | Suction Motor Type | Brushless DC Motor | |
| Drive Wheel Motor Type | Brushed DC Motor | ||
| Battery | Battery Capacity (mAh) | 650 | |
| Battery Type | Lithium-ion Cells | ||
| Charging Current (mA) | Approx. 300 (at constant current) | ||
| Accessories | Adapter | Output Parameters: Voltage (V), Current (A) | 24V 3A |
| Input Parameters: AC (V), Frequency (Hz), Current (A) | AC 100–240V, 50/60 Hz, 2.5A | ||
| Safety Rope | Safety Rope Load Capacity (Kgf) | 150 | |
| Safety Rope Length | 5 m | ||
| Cleaning Cloth | Quantity | 8 Blades | |
| Other | Sensor | Distribution and Category | 1. 6-axis sensor (on the mainboard) 2. Barometric pressure sensor (on the button board) |
| Certification | CE | YES | |
| KC | YES | ||
Product Features
1. High-speed cleaning efficiency
The high-speed rotating cleaning disc improves wiping speed, covers large glass in short time, reduces working time and improves cleaning efficiency for home scenes.
2. Stable adsorption & safety protection
Strong vacuum suction with anti-fall & power-off protection. The High Speed Window Robot Cleaner
stays firmly on glass even for high-rise windows, ensuring safe use for families.
3. Intelligent path & full coverage
Auto plans cleaning route, no missing areas. It identifies glass edges automatically, suitable for different sizes of home windows.
4. Atomizing spray & no water marks
Double-sided atomizing water system sprays evenly, dissolves dust and oil stains. Wiping leaves no water marks, glass keeps transparent for a long time.
Comparison with Similar Products
1. Cleaning speed: Our high-speed motor runs at 200r/min, faster than ordinary products, saving more time.
2. Adsorption stability: 3200Pa strong suction with dual safety protection, more stable than ordinary products on high-rise windows.
3. Cleaning effect: Double-sided atomizing spray + high-speed wiping, removes stains more thoroughly and leaves no water marks.
4. Quality control: As a professional manufacturer, we have complete certifications and strict testing, more reliable than trading companies.
